BIOS SETUP
IB893 User’s Manual
29
Onboard Serial Port
The default values are:
Serial Port 1: 3F8/IRQ4
Serial Port 2: 2F8/IRQ3
Serial Port 3: 3E8/IRQ11
Serial Port 4: 2E8/IRQ10
Restore on AC Power Loss
This field sets the system power status whether Power On or Power Off
when power returns to the system from a power failure situation.
BIOS SETUP UTILITY
Advanced
Hardware Health Configuration
Options
Disabled
70°C/158°F
75°C/167°F
80°C/176°F
85°C/185°F
90°C/194°F
95°C/203°F
<- Select
Screen
↑↓ Select
Item
+- Change Option
Tab Select Field
F1 General
Help
F10 Save and Exit
ESC Exit
System Temperature
:42°C/107°F
CPU Temperature
:37°C/98°F
CPU FAN Speed
:6750 RPM
Vcore :1.136
V
12 V
:11.904 V
3.3V
:3.408 V
1.5V
:1.504V
VBAT
: 3.536V
CPU Shutdown temperature
[Disabled]
The Hardware Health Configuration menu is used to show the operating
temperature, fan speeds and system voltages.
CPU Shutdown temperature
The system will shut down automatically under OS with ACPI mode,
when the CPU temperature reaches the configured temperature.
