INTRODUCTION
IB893 User’s Manual 3
IB893 Specifications
Product Name IB893
Form Factor 3.5”
CPU Type Intel ® Pineview-D DC Processor
CPU Speed Intel ® Atom TM DC D525 / 1MB cache/1.66GHz (13W)
22mm x 22mm, Micro-FCBGA8
BIOS AMI BIOS
Chipset ICH8M: 31mm x 31mm,T-PBGA (2.4W)
Memory DDR3-800MHz
SO-DIMM x 1 (w/o ECC), Max. 4GB , Single channel
VGA Intel ® Integrated Graphics Controller
Supports DirectX 9 Graphic (200MHz/ 400MHz), OpenGL 1.4
LVDS Xilinx XC3S200AN-4FTG256C FPGA for converting 18-bit to 24-bit
Support 24-bit dual channels LVDS interface w/DF13 socket x2
LAN Realtek 8111G-CG x 2 (32-pin QFN package)
USB ICH8M built-in USB 2.0 host controller, support 8 ports
Serial ATA Ports ICH8M built-in SATA controller, supports 2 ports
Audio Intel ICH8M built-in audio controller w/ Realtek ALC662-VD Codec
(supports 5.1 CH audio & SSM2304 2W/4ohm Amplifier
LPC I/O Nuvoton NCT6627UD:
COM1 (RS232/422/485) [EXAR SP339EER1 232/422/485
transceiver x 1 for jumper-less]
COM2~COM4 (RS232 only) with pin-9 with power for 2 ports (500
mA for each port) **EXAR SP3243EBER x 3**
Hardware monitor (2 thermal inputs, 4 voltage monitor inputs,
VID0-4 & 1 x Fan Header)
Digital IO 4 in & 4 out
Keyboard/Mouse
Connector
Thru pin-headers
Expansion Slots Mini PCI-e socket x 1 (w/ USB signal)
Edge Connector DB15 x1 for VGA
RJ45 x2 for LAN 1&2
USB stack connector x 1 for USB1 ~2
DB9 x 1 for COM1
On Board
Header/Connector DF11 2x4-pin socket for KB/mouse
2x4-pin header x 3 for 6 USB ports
DF13 socket connector x 2 for 24-bit dual channel LVDS
2x6-pin box header x1 for Audio
4-pin header x1 for speaker
2x5-pin box header x 1 for COM2
2x10-pin box header x 1 for COM3 ~4
2x5-pin headers x 1 for LPC (80-port card debugging purpose)
Mini PCI-e(1x) connector x 1
4-pin box header x 1 for backlight/brightness control
4-pin power connector x 2 for SATA HDD
Watchdog Timer Yes (256 segments, 0, 1, 2…255 sec/min)
Power Connector +12V DC-in
RoHS Yes
Board Size
102mm x 147mm
