BIOS SETUP
40
IB893 User’s Manual
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot
Security
Chipset
Exit
South Bridge Chipset Configuration
Options
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
10 USB Ports
<- Select
Screen
↑↓ Select
Item
+- Change Option
F1 General
Help
F10 Save and Exit
ESC Exit
USB Function
[10 USB Ports]
USB 2.0 Controller
[Enabled]
HAD Controller
[Enabled]
SMBUS
Controller
[Enabled]
PCIE Ports Configuration
PCIE Port 0
[Auto]
PCIE Port 1
[Auto]
PCIE Port 2
[Auto]
PCIE Port 3
[Auto]
PCIE Port 4
[Auto]
PCIE Port 5
[Auto]
PCIE High Priority Port
[Disabled]
PCIE Port 0 IOxAPIC Enable [Disabled]
PCIE Port 1 IOxAPIC Enable [Disabled]
PCIE Port 2 IOxAPIC Enable [Disabled]
PCIE Port 3 IOxAPIC Enable [Disabled]
PCIE Port 4 IOxAPIC Enable [Disabled]
PCIE Port 5 IOxAPIC Enable [Disabled]
Enable Onboard PCI option ROM
[Disabled]
USB Function
Enables the number of USB ports desired or disables the USB function.
USB 2.0 Controller
This option is disabled by default.
HDA Controller
This option is used to enable the Southbridge high definition audio
controller.
SMBUS Controller
This option is enabled by default.
Clock-Gen Spectrum
This option is disabled by default.
Enable Onboard PCI option ROM
This option is disabled by default.
