BIOS SETUP
34
IB893 User’s Manual
PCIPnP Settings
This option configures the PCI/PnP settings.
BIOS SETUP UTILITY
Main Advanced
PCIPnP
Boot
Security Chipset
Exit
Advanced PCI/PnP Settings
NO: lets the BIOS
Configure all the
Devices in the system.
YES: lets the
operating system
configure Plug and
Play (PnP) devices not
required for boot if
your system has a Plug
and Play operating
system.
<- Select
Screen
↑↓ Select
Item
+- Change Option
F1 General
Help
F10 Save and Exit
ESC Exit
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Clear NVRAM
Plug & Play O/S
PCI Latency Timer
[No]
[No]
[64]
Allocate IRQ to PCI VGA
Palette Snooping
PCI IDE BusMaster
OffBoard PCI/ISA IDE Card
[Yes]
[Disabled]
[Disabled]
[Auto]
IRQ3
[Available]
IRQ4
[Available]
IRQ5
[Available]
IRQ7
[Available]
IRQ9
[Available]
IRQ10
IRQ11
IRQ14
IRQ15
DMA Channel 0
DMA Channel 1
DMA Channel 3
DMA Channel 5
DMA Channel 6
DMA Channel 7
Reserved Memory Size
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Disabled]
Plug & Play O/S
This lets BIOS configure all devices in the system or lets the OS
configure PnP devices not required for boot if your system has a Plug
and Play OS.
Allocate IRQ to PCI VGA
This assigns IRQ to PCI VGA card if card requests IRQ or doesn't assign
IRQ to PCI VGA card even if card requests an IRQ.
IRQ#
Use the IRQ# address to specify what IRQs can be assigned to a
particular peripheral device.
