Description
2013-08-13
23
3.6.9 Model L481-BHHCL
CPU Module
4
3
5
1
2
Rear View
1 Service
port
2
Connect to interconnect cable
3
To CPU: USB-HID
4
To CPU: HDMI
5
Local output: HDMI
Pos: 23 /806-IHSE/Beschreibung/Geräteansichten/481-xx/Typ L481-BHHCLR @ 9\mod_1373967886182_6.doc @ 77552 @ 3 @ 4
3.6.10 Model L481-BHHCLR
CPU Module
4
5
6
1
2
3
Rear View
1 Service
port
2
Connect to interconnect cable 1
3
Connect to interconnect cable 2
4
To CPU: USB-HID
5
To CPU: HDMI
6
Local output: HDMI
