Draco KVM Extender
66
2013-08-13
Compatibility AES/EBU, S/PDIF, EIAJ CP1201,
IEC 60958
Standards Dolby Digital, DTS, PCM
Bit Depth 24 bit
Sample Rate 32 to 96 kHz
CPU Unit (Inputs)  Mini-XLR (AES/EBU; symmetrical,
lockable)
 Coaxial (S/PDIF; RCA, Cinch)
 Optical (S/PDIF; TOSLINK)
CON Unit (Outputs)  Mini-XLR (AES/EBU; symmetrical,
lockable)
 Coaxial (S/PDIF; RCA, Cinch)
 Optical (S/PDIF; TOSLINK)
Pos: 91 /806-IHSE/Technische Daten/Verbindungskabel/UEB_Verbindungskabel @ 5\mod_1279191107845_6.doc @ 43870 @ 2 @ 1
7.2 Interconnect Cable
Pos: 92 /806-IHSE/Technische Daten/Verbindungskabel/Verbindungskabel (Cat X) @ 5\mod_1278578406026_6.doc @ 42205 @ 3 @ 1
7.2.1 Cat X
A point-to-point connection is required. Operation with several patch fields
is possible. Routing over an active network component, such as an
Ethernet Hub, Router or Matrix, is not allowed.

Avoid routing Cat X cables along power cables.
 If the site has 3-phase AC power, try to ensure that CPU Unit and
CON Unit are on the same phase.
To maintain regulatory EMC compliance, correctly installed shielded Cat X
cable must be used throughout the interconnection link.
To maintain regulatory EMC compliance, all Cat X cables need to carry
ferrites on both cable ends close to the device.
