Draco KVM Extender
30
2013-08-13
3.6.24 Model L- / R474-BAX
CPU Module
CON Module
1
2 3
1
2 3
Rear View
Rear View
1
Connect to serial (D-Sub 9)
2 Audio
IN
3 Audio
OUT
1
Connect to serial (D-Sub 9)
2 Audio
IN
3 Audio
OUT
Pos: 39 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BAP @ 9\mod_1362472648439_6.doc @ 71250 @ 3 @ 4
3.6.25 Model L- / R474-BAP
CPU Module
CON Module
1
2 3
4
5
1
2 3
4
5
Rear View
Rear View
1
Connect to serial (D-Sub 9)
2 Audio
IN
3 Audio
OUT
4
To CPU: PS/2 mouse
5
To CPU: PS/2 keyboard
1
Connect to serial (D-Sub 9)
2 Audio
IN
3 Audio
OUT
4
Connect to PS/2 mouse
5
Connect to PS/2 keyboard
Pos: 40 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BXP @ 8\mod_1348579797358_6.doc @ 69420 @ 3 @ 1
