Draco KVM Extender
46
2013-08-13
Upgrade Module USB 2.0 Embedded:
1. Connect the CPU with the CPU Unit (USB 2.0).
2. Connect the USB 2.0 devices with the CON Unit (Connect to
USB 2.0 devices).
Upgrade Module USB 2.0:
1. Connect the CPU with the CPU Unit (USB 2.0).
2. Connect the USB 2.0 devices with the CON Unit (Connect to
USB 2.0 devices).
Pos: 65 /806-IHSE/Installation/Installationsbeispiele/UEB_Installationsbeispiele @ 5\mod_1278581564870_6.doc @ 42759 @ 2 @ 1
4.3 Example Applications
This section illustrates typical installations of KVM Extenders:
Pos: 66 /806-IHSE/Installation/Installationsbeispiele/477-xx_COMP @ 5\mod_1291124264328_6.doc @ 44767 @ @ 1
1 2 4 5 3
KVM Extender (Single-Head)
