LED 3: USB and Video Status
LED color Description
Red Device ready
Violet
Connection and USB signal (interconnect) available
Green Connection and video signal available
Light Blue
Connection, USB and video signal available
(operating status)
LED 4: Locally Connected Source Status
LED color Description
Green Video signal of locally connected source (computer,
CPU) available
Light Blue Video and USB signal switched from locally
connected source (computer, CPU)
