3.8 Trace Function
All events, e.g. activities and switching operations of the Draco tera matrix,
are logged and displayed in this menu.
This function is used for diagnostic purposes.
You have the possibility to request various trace views in the menu:
The following information is shown in this menu:
Field Description
Date Date stamp
Time Time stamp
Message Detailed description of the event
Trace possibilities
 Select Status > Trace IO Board in the main menu to check the
events on your current I/O board.
 Select Status > Trace Matrix to check the matrix events.
