Installation
2013-08-14
49
4.3.2 Video Matrix
If you use the Draco tera as a video matrix, up to 288 input ports can be
switched to up to 288 output ports depending on components and
equipment.
1 2 2 3 4
Video Matrix
1 Video source (e. g. SDI camera)
2 Interconnect cable
3 Draco tera matrix
4 Video sink (e. g. monitor)
