K238 Media- / DVI-Converter
18
2013-08-13
4.3 Example Applications
This section illustrates typical installations of Media- / DVI-Converters:
Pos: 19 /806-IHSE/Installation/Installationsbeispiele/238-5v-xx @ 5\mod_1291133686078_6.doc @ 45348 @ @ 1
1 2 3
Media- / DVI-Converter (Video Input: Composite)
1 Source (observation camera)
2 Media- / DVI-Converter
3 Monitor
1 2 3
Media- / DVI-Converter (Video Input: S-Video)
1 Source (DVD player)
2 Media- / DVI-Converter
3 Monitor
