8
2 CB-7000 Utility User Manual
2.1 Overview
This section contains the following:
• Introduction of 7000 Utility
• Package of 7000 Utility
• Installation of 7000 Utility
• Uninstall the 7000 Utility
• Start the 7000 Utility
• Operation of 7000 Utility
• Change baud rate and checksum
• Exit the 7000 Utility
2.2 Introduction
The 7000UTIL.EXE is a software utility for C B-7000 modules. It works in multiple baud rate
environments to meet the specification of “Self-Tuner” of 7000 m odules. It provides the
following capabilities:
• Detection of CB-7000 modules connected to the Host PC.
• Setting module configuration.
• Executing data input and/or output for every connected CB-7000 module.
• Saves the information for the detected CB-7000 modules into a file (with .map extension file
name).
Please refer to the following content to complete the installation procedure.
2.3 Package of 7000 Utility
The 7000 Utility package includes a setup disk.
2.4 Installation of 7000 Utility
Before installing, please confirm the following requirements are met:
• Microsoft Windows 95/98/NT 4.0 operation system.
• 16 MB RAM Memory.
• 10 MB hard disk available space.
Starting the Installation:
1. Insert the 7000 Utility setup disk into the disk drive.
2. Click "Start" in the task bar, then click "Run".
3. Enter "A: Setup.exe" as shown in Figure 2-1 (or whatever drive letter applies).
4. Click “OK” to start the installation procedure.
5. Follow the instructions in the installation procedures.
