Universal Library Virtual Instruments (VIs)
Miscellaneous VIs
BIDMACHAN
- DMA channel. 0, 1 or 3
BIINITIALIZED
- TRUE (non-zero) or FALSE (0)
BICLOCK
- Clock frequency in MHz (1, 4, 6, or 10); or (0) for not supported.
BIRANGE
- Selected voltage range. For switch-selectable gains only. If the selected A/D board does not
have a programmable gain feature, this argument returns the range as defined by the installed InstaCal
settings which correspond to the input range as set via the switches on the board. Refer to board-specific
information for a list of the A/D ranges supported by each board.
Range Value
Range
Value
±20 V
15
0 - 5 V
101
±10 V
1
0 - 4 V
114
±5 V
0
0 - 2.5 V
102
±4 V
16
0 - 2 V
103
±2.5 V
2
0 - 1.67 V
109
±2 V
14
0 - 1.25 V
104
±1.67 V
11
0 - 1 V
105
±1.25 V
3
0 - 0.5 V
110
±1 V
4
0 - 0.25 V
111
±0.625 V
5
0 - 0.2 V
112
±0.5 V
6
0 - 0.1 V
106
±0.25 V
12
0 - 0.01 V
107
±0.2 V
13
0 - 0.02 V
108
±0.1 V
7
4 -20 mA
200
±0.05 V
8
0 -20 mA
204
±0.01 V
9
2 -10 mA
201
±0.005 V
10
1- 5 mA
202
0 - 10 V
100
0.5 to 2.5 mA
203
BINUMADCHANS
- Number of A/D channels
BIUSESEXPS
- Supports expansion boards TRUE/FALSE
BIDINUMDEVS
- Number of digital devices
BIDIDEVNUM
- Index into digital information for first device
BICINUMDEVS
- Number of counter devices
BICIDEVNUM
- Index into counter information for first device
BINUMDACHANS
- Number of D/A channels
BIWAITSTATE
- Setting of Wait State jumper. 1 = enabled, 0 = disabled
BINUMIOPORTS
- Number of IO ports used by board
BIPARENTBOARD
- Board number of parent board
BIDTBOARD
- Board number of connected DT board
