2.6 A very brief guide to Gyda mode set-up
All of these settings are covered in much more detail in chapter 3.2. These are just the most
important settings to get started:
Arguably the most important setting is where to take the input from. Since the module is
only available with one single electrical BNC input per frame sync core, a good starting
point would be to take the input from these BNCs:
What this means is that the electrical input will be chosen whenever a signal is present, and
if a signal is not present, the output will frame freeze for 500 ms before resorting to an
internal fallback generator. Here this generator is set to produce Colourbar.
2.7 How to get back to factory defaults?
To access the function that will reset the module and reload the factory default settings, the
module must briefly be put into manual mode. The entire procedure is described in chapter
0.
