Appendix B
Specifications
Electrical SDI inputs
Connectors
75 Ohm BNC
Equalization
Automatic;
>300m @270Mbps w/Belden 8281, with BER < 10E-12
>100m @1485Mbps w/Belden 1694A, with BER < 10E-12
Input Return loss
>15dB, 5MHz -1.5GHz
Jitter tolerance
SD limit:
10Hz-1kHz: >1 UI
10kHz
– 5MHz: >0.2 UI
HD limit:
10Hz-100kHz: >1 UI
100kHz
–10MHz: >0.2 UI
Electrical Sync input
Connector
75 Ohm BNC
Format
Black & Burst, Tri-level
Input Return loss
Termination
>35dB @ < 10MHz,
30dB @ < 30MHz
Selectable internal or external 75 Ohm termination
Electrical SDI outputs
Number of outputs
4
Connectors
75 Ohm BNC
Output Return loss
>15dB, 5MHz -1.5GHz
Output signal level
800mV +/- 10%
Output signal rise / fall time
20% - 80%
SD limit: [0.4ns
– 1.5ns]; <0.5ns rise/fall var.
HD limit: < 270ps, <100ps rise/fall var.
Amplitude overshoot
<10%
Output timing jitter
SD: <0.2 UI
HD: <1 UI
Output alignment jitter
SD: <0.15 UI
HD: <0.15 UI
Supported standards
SD, 270 Mbps
SMPTE 259M
HD, 1485 Mbps
SMPTE 274M, SMPTE 291M, SMPTE 292M, SMPTE 296M
3G, 2970 Mbps
SMPTE 291M, SMPTE 424M, SMPTE 425M
Video switch point definition
and sync
SMPTE RP168 (tri-level), SMPTE 170m, ITU-R. BT.470
AES
AES3-1996
EDH
Compliant to SMPTE-RP165
Power consumption (+5 VDC)
Maximum power, at 50°C
11.1 W
2
2
Actual power consumption varies with the video standards used. Please see the complete table under Power requirements,
chapter 2.1.
