6. System Setup and Operation
How to Realize LED Display Connection
VSP 9516S User Manual 105
e. Turn the knob, and choose <D PORT Offset (A/B) Y>, and set D PORT Offset (A/B) Y
as 240 (Note: D PORT Offset (A/B) Y=HORIZONTAL CARD×HEIGHT, before we set
horizontal card as 2 and height as 120). Shown as follows:
f. Turn the knob, choose <DISPLAY CONNECTION>, push the knob to confirm, turn the
knob again, and choose <CONNECTION MODE>. the OLED module show as follows:
Choose the connection mode, the setting is same as Port U1. Then connection of both the
Port D and Port U of One Sending Card to LED Display is finished.
Rendering is as follows:
> CHOOSE CABLE PORT D
HORIZONTAL CARD 2
VERTICAL CARD 3
WIDTH 120
> HEIGHT 120
D PORT Offset (A/B) X 0
D PORT Offset (A/B) Y 240
DISPLAY CONNECTION >>
HEIGHT 120
D PORT Offset (A/B) X 0
D PORT Offset (A/B) Y 240
> DISPLAY CONNECTION >>
> CONNECTION MODE
SEND TO RECEIVER
