7
Remote Control Unit
1. Remove the battery compartment cover.
2. Insert two “AA” (R6 or SUM-3) dry batteries. Make sure that
the batteries are inserted with their positive “+ ” and
negative “_” poles positioned correctly.
3. Close the cover.
Battery Replacement
If the distance required between the remote control unit and
main unit decreases, the batteries are exhausted. In this case
replace the batteries with new ones.
Precautions concerning batteries
< Be sure to insert the batteries with correct positive “+” and
negative “_” polarities.
< Use batteries of the same type. Never use different types of
batteries together.
< Rechargeable and non-rechargeable batteries can be used.
Refer to the precautions on their labels.
< When the remote control unit is not to be used for a long
time (more than a month), remove the batteries from the
remote control unit to prevent them from leaking. If they
leak, wipe away the liquid inside the battery compartment
and replace the batteries with new ones.
< Do not heat or disassemble batteries and never dispose of old
batteries by throwing them in a fire.
The provided Remote Control Unit allows the unit to be operated
from a distance.
When operating the remote control unit, point it towards the
remote sensor on the front panel of the unit.
< Even if the remote control unit is operated within the effective
range (5m), remote control operation may be impossible if
there are any obstacles between the unit and the remote
control.
< If the remote control unit is operated near other products
which generate infrared rays, or if other remote control
devices using infrared rays are used near the unit, it may
operate incorrectly. Conversely, the other products may
operate incorrectly.
Battery Installation
POWER (STANDBY/ON)
Press this switch to turn the unit on or standby (clock mode).
When using the remote control unit, press the ON button to
turn the unit on, and press the STANDBY button to turn it
standby.
Numeric buttons
These are used either to directly input frequency numbers or
to select preset stations.
DIRECT TUNING
Press this button and you can use the numeric buttons to
directly input frequency numbers.
Display
TIMER
Press this button to put the tuner under the control of a built-
in timer in terms of automatically switching on power to the
unit at a predetermined time and turning it off after a
predetermined time period.
FM MODE
This button toggles Stereo and Mono modes.
TUNING MODE
Press this button to toggle Preset and Tuning modes.
TUNING/PRESET/TIME
These buttons are used to: 1) search out stations; 2) let the
unit tune in to a preset station; and 3) set a built-in clock and
timer.
AM/FM
Use this button to select either of the frequency bands.
MEMORY/SET
This button is used either to store stations in presets or to set
a built-in clock and timer.
SLEEP
This button lets you set a time at the end of which this unit
automatically switches itself off.
TIME SET
Press this button and the MEMORY/SET button is available to
set a built-in clock and timer.
Remote control sensor
Receives signals from the remote control unit. Point the
remote control unit at this sensor when operating the remote
control unit.
M
L
K
J
I
H
G
F
E
D
C
B
The equipment draws a nominal amount of power from the
AC outlet even with its POWER switch in the OFF position.
A
