707018-006 5-1
Chapter 5. e Term 350 Plus
Connection Types
HostConnect is the application which provides simultaneous connections to a variety
of host systems using the Telnet protocol over TCP/IP on an Ethernet network.
HostConnect provides TN5250 emulation for access to IBM AS/400 systems, TN3270
terminal emulation for connection to IBM Mainframe systems, and ASCII terminal
emulation for connection to RS/6000, DEC, HP and other ASCII host computers. In
addition, HostConnect supports the TN5250E and TN3270E protocols, giving you access
to advanced features such as device-name selection, sign-on bypass and printing.
Host sessions can be configured to start automatically each time eTerm 350 is started or
you can start sessions as needed from the HostConnect Desktop or the menu bar in an
emulation session. HostConnect session types include:
• TN5250
TN5250 is a full featured emulation of the IBM 5250 twinax terminal and includes
support for Field Attributes, Text Assist and other unique 5250 functions.
Local screen printing is supported to a local-attached PCL5 printer ONLY.
• TN5250E Printer
TN5250E Printer emulating the IBM 3812-1 supports AS/400 Host Print Transform
using the AS/400 resident print drivers.
• TN3270
Emulating the IBM 3278 coax terminal, it includes full terminal emulation support
for 3270 keys and the screen attributes of a 3278 terminal session.
Local screen printing is supported to a local-attached PCL5 printer ONLY.
• TN3270E Printer
TN3270E Printer emulating the IBM 3287 supports host LU1 and LU3 data streams.
This driver ONLY supports PCL5 printers.
• ASCII
HostConnect also provides VT100 and 220 terminal emulation in a graphical window.
It contains substantial enhancements to the standard VT functions, including local
screen print to a local-attached PCL5 printer and color command support. These
features can be selected either from the pull-down menus or VT command sequences.
