iP380 User Manual
Welltech Technology Co., Ltd.
92 / 104 2012/11/01
Item Explanation
Body Signal=16, Duration=250].
Encrypt Type Default: Disable; Set up SIP encrption type.
When this function is on, system will send out encryption information
according to encryption type.
Provide options: Disable, INFINET, AVS, WALKERSUN1, WALKERSUN2,
CSF1, CSF2, GX, VGX, RC4, VOS_R, VGCP.
*This function must be supported by SIP Server.
Encrypt Key Set up encryption key.
Some encryption type will ask you to enter the keys to encrypt the
information.
This column can enter numbers or strings; maximum length is 63
bytes.
*This function must be supported by SIP Server.
PPPoE Retry Period Default: 5; When iP380 failed to connect PPPoE, it will wait for several
seconds and try to connect PPPoE again.
This column can only enter numbers; maximum length is 3 bytes with
a range of 5~255(seconds).
DHCP Gateway ARP
Check Period
Default: 0; When use DHCP mode to get IP address, How often to
check default gateway there. This column can only enter numbers; If
the parameter is 0, that mean disable this feature. Maximum length is
3 bytes with a range of 30~300(seconds).
Syslog Server IP
Address
Set up Syslog address; The Syslog Server will receive Debug Log from
iP380. This column can enter numbers or strings with the type of
xxx.xxx.xxx.xxx; maximum length is 63 bytes.
System Log Default: Disable; Provide options: Disable, Call Statistics, General
Debug, Call Statistics, General Debug, SIP Debug, Call Statistics + SIP
Debug, General Debug + SIP Debug, All.
NET Bandwidth
Limit Default: Disable; Set up the transmission limit through LAN Port.
When this function is on, iP380 will limit the transmission through LAN
Port according to the option.
Provide options: Disable, 128, 256, 512, 1024, 2048, 4096,
8192(Kbps).
Relay control Default: Disable; This function is to control external device via remote
DTMF 0 or via incoming Ring . Provide drop-down options: Disable,
DTMF Control (Received RFC2833 DTMF digit 0 to control), Ring
Control (Received incoming ring signal to control).
Relay Mode Default: Normal Open. When the Relay was triggered, the status was
closed until triggered signal was disappeared. Provide drop-down
options: Normal Open, Normal Close.
Submit [Button] Save the settings.
2.5.5.3. Operate Instruction
Example 1: System Log (Please Start TFTP or System Log Server)
 System Log Type: All
Step 1: In [Management - Advanced Setting] web page, Set up [System Log Server:
192.168.50,99, System Log Type: All] (See Figure 1).
