Dimensions
08
NETWORK AF ZOOM CAMERA
Part Names
(unit : mm)
267
108
87.30
100 86.40 75.90
80
190
DUAL WINDOW
SUNSHIELD BOLT
SUNSHIELD
FRONT CASE
EASY
BRACKET
OSD Setup
CONTROL COVER
LOCK/UNLOCK
SCREW
BRACKET
REAR CASE
ETHERNET &
POWER CABLE
