3-5
ALL STOP (F2) Command (Version 5.1 and Later)
ALL STOP (F2) Command (Version 5.1 and Later)
The ALL STOP command is issued to set all or a speciÞc part of the switcher to a
known state. The command causes the following functions to occur:
1. An ongoing KEY 1 MIX or KEY 2 MIX is stopped.
2. An ongoing AUTO TRAN (Transition) is stopped.
3. An ongoing EFF DIS (Effects Dissolve) is stopped.
4. An ongoing SEQ (Sequence) is stopped.
5. The lever arm is set to a limit.
6. The transition type is set to MIX.
7. The transition mode is set to BKGD in Standard Mode and BKGD A in
Layered Mode.
8. For Standard mode, all Keys are removed. For Layered mode, all Keys
are left alone.
9. The crosspoint selections remain unchanged.
Table 3-1. All Stop Command
Effects Addresses
Valid effects addresses for the ALL STOP command are as follows:
EFFECTS ADDRESS ASSIGNMENTS
00 PGM-PST Mix System
01 Mix/Effects 1 System
02 Mix/Effects 2 System
03 Mix/Effects 3 System
04 Downstream Keyer (DSK)
05 Background (BKGD)
06 Miscellaneous (MISC)
07 DPM 1
08 DPM 2
09 DPM 3
0A DPM 4
0B All levels
Function
Byte
Count Effects
Address Command
Code
Message
Write 03 EX F2 FF
