3-36
Section 3 Ð Editor Interface Commands
Mode Byte
The Mode byte allows an E-MEM learn with Effects Dissolve.The format of the
Mode byte is as follows:
Setting Bit 6 to one causes an Effects Dissolve to automatically occur when the
speciÞed E-MEM register is recalled.
1
Registers
Valid E-MEM registers are 00 through 99 (00HÐ63H).
The format of the Effects Register Number byte is as follows:
1. Not supported in Version 5.0 and earlier.
Bit Bit
7 6 5 4 3 2 1 0
X 0 X X X X X X
1 = Learn with Effects Dissolve
Bit Bit
7 6 5 4 3 2 1 0
0 X X X X X X X
1 = Effects Register 00H– 63H
