4-4
Section 4ÑParameter-Based Command Set
Valid base system addresses for this command are as follows:
Data
This data is represented as a 1 byte hex value.
The crosspoint #'s fall in the range of 1 to the maximum value based on the
panel type (1 through 20 hex for a 16 source button switcher, and 1 through
30 hex for a 24 source button switcher), plus the re-entry crosspoints.
Re-entry crosspoint numbers are the same for any switcher type:
Example
To Þnd out the currently selected crosspoint on the Key1 bus for M/E 2,
send the following command:
0 5 0 2 4 5 0 0 0 0 0 3
The switcher returns:
0 7 0 2 c 5 0 0 0 0 0 3 d d w h e r e d d i s t h e c r o s s p o i n t #
Base System
Addresses
Assignments
00 01 PGM or A bus
00 02 PST or B bus
00 03 DSK1 or Key1
00 04 DSK2 or Key2
Crosspoint # Re-entry Position
31 (hex) Mix Effects 1
32 Mix Effects 2
33 Mix Effects 3
