Section 3 Ð Editor Interface Commands
Select “Layered” Or “Standard” (E8) Command
Using this command, an editor can select for each Mix/Effects section either the
Standard or Layered mode of operation.
Table 3-22. Select ÒLayeredÓ or ÒStandardÓ Command
Effects Addresses
Valid Effects Addresses for the Select Layered/Standard command are as follows:
EFFECTS ADDRESS ASSIGNMENTS
00 PGM-PST Mix System (Model 4000-2A only)
01 Mix/Effects 1 System
02 Mix/Effects 2 System
03 Mix/Effects 3 System
Mode Byte
The format of the Mode byte is as follows:
Function
Byte
Count Effects
Address Command
Code
Message
Layered or Standard Mode 03 EX E8 (Write) Mode byte
Bit Bit
7 6 5 4 3 2 1 0
S/L 0 0 0 0 0 0 0
0 = Standard Mode
1 = Layered Mode
