3-11
Crosspoint Bus (E2) Command (PVW)
Crosspoint Bus (E2) Command (PVW)
The Write Crosspoint Bus command enables the editor to select any crosspoint on
a bus speciÞed by the effects address.
Table 3-7. Crosspoint Bus Command
Effects Addresses
Valid effects addresses for the Crosspoint Bus command are as follows:
EFFECTS ADDRESS ASSIGNMENTS
06 PVW Bus (MISC)
Crosspoint Numbers
Valid crosspoint numbers are shown in Table 3-3, ÒCommon Crosspoint Numbers
for All Buses,Ó on page 3-7.
Function
Byte
Count Effects
Address Command
Code
Message
Write Crosspoint Bus 03 EX E2 (Write) Crosspoint #
