4-9
E-MEM Parameter Control
07 DPM 1
08 DPM 2
09 DPM 3
0a DPM 4
0b All Enabled Levels (enables control) – or –
Master Timeline (register control)
Valid sub-system addresses for these commands are as follows:
Valid base-system addresses for these commands are as follows:
Data
T w o b y t e d a t a
Two bytes of data are returned when the base address is 02 00 (enables
control) and the effects address is 0b (all enabled levels). This query is
asking the switcher what are all the currently enabled levels. The data
returned for this query is a 2 byte bit mask, with each of the lower 11
bits representing a distinct level. A bit ON means the associated level is
ON. The top 5 bits will always be zero.
Subsystem Addresses Assignments
02 E-MEM sub-system
Base System Addresses Assignments
02 00 Enables control
02 01 Register control
