83

CR6400

User’s Guide

Audio Specifications

CR6400 Digital Audio (AES) Specifications

Drawings

The following drawings identify features and provide overall and critical dimensions.

Specification

Detail

Signal inputs

Signal type: AES3id (2 “mono” channels per input).

Sample rate: 32 kHz

192 kHz.

Input level: 1V p-p nominal into 75

W.

Input range: 200 mV p-p to 3 V p-p into 75

W.

Input return loss: < –25 dB, from 100 kHz to 6 MHz.

Input connectors: BNC, 75

W.

Signal outputs

Signal type: AES3id (2 “mono” channels per input).

Sample rate: async, 32 kHz

192 kHz; sync, 48 kHz.

Output level: 1V p-p ± 10% into 75

W.

Output offset: 0.0 VDC ± 50 mVDC, AC coupled.

Output rise/fall time: 4 ns

8 ns.

Output jitter: < 1ns, in synchronous mode.

Output return loss: < –25 dB, from 100 kHz to 6 MHz.

Output-to-output isolation: > 40 dB, from 100 kHz to 6 MHz.

Output connectors: BNC, 75

W.
