LDK 4488, LDK 4489 SuperXpander, Xpander User’s Guide (v5.0) 27
Chapter 3 - Assembly
3.7 Cable clamp
When the lens and camera are mounted on the SuperXpander/Xpander it is necessary to
clamp the camera Triax or fiber cable. Proceed as follows:
1. Loosen the cable clamp on the right side of the footbed by turning it counterclockwise.
2. Put the cable into the clamp.
3. Tighten the cable clamp by turning it clockwise.
4. When connected to the camera, run the flying lead through the bottom clamp at the rear
of the SuperXpander/Xpander to keep it from blocking the control panel. When not
connected to the camera, run it through both clamps.
3.8 Mounting a scriptboard
An optional scriptboard can be mounted on the right or left side of the SuperXpander/Xpander.
To mount the scriptboard onto the SuperXpander/Xpander insert the pin into the scriptboard
hole of the SuperXpander/Xpander. Tighten the screw and adjust the scriptboard.
