LDK 4488, LDK 4489 SuperXpander, Xpander User’s Guide (v5.0)
29
Chapter 4 - Control panel
Chapter 4
Control panel
4.1 Buttons
The LDK 4488 SuperXpander is equipped with a control panel at the rear of the unit . This panel
includes an LCD screen and buttons for controlling the camera and the viewfinder. The buttons
on the control panel have coloured backlighting that indicates the state of the button.
4.2 LCD display panel controls
Button state
Description
Blue
Function is available but not selected.
Yellow
Function is selected and active.
Yellow (blinking)
Function is selected but has unusual behaviour.
Off
Function is unavailable.
MENU
1
MENU
2
+
-
PREV
NEXT
MENU
3
MENU
4
ON AIR
DIM
INDI-
CATOR
VF
ZOOM
Y/-Y
Y/EXT
MARKER
TEXT
ON AIR
POWER
REMOTE
R/-R
EXT 1
SELECT
CENTER
CROSS
VF
DETAIL
G/-G
EXT 2
SAFE
AREA
FOCUS
ASSIST
B/-B
EXT
ASPECT
RATIO
PROG
ENG
PROD
CALL
V
F
I
N
T
E
R
C
O
M
plus/minus
buttons
previous/next
buttons
menu
buttons
item
selectors
menu
buttons
display
panel
item
selectors
