LDK 4488, LDK 4489 SuperXpander, Xpander User’s Guide (v5.0) 39
Chapter 6 - Connectors
Chapter 6
Connectors
6.1 Left side view
Flying lead (connects
to camera)
Triax or fiber connection
to Base Station
lens interface
connector
Utility power
outputs
15V =
50W 5-12V =
50W
DC OUT
Fixed power
output
Flying lead
(connects to
the camera)
Triax connection to
Base Station
Variable power output
(SuperXpander only)
