LDK 4488, LDK 4489 SuperXpander, Xpander User’s Guide (v5.0) 45
Chapter 7 - Specifications
Chapter 7
Specifications
7.1 Specifications for LDK 4488, LDK 4489
Item Value
Power
Power requirements 100 to 240 VAC; 50 to 60 Hz 3 A; fuses (2x): T4.0 AH 250 V
Power consumption 250 VA max. fully equipped
Power connection IEC type 3-pin male
Environment
Operating temperatures 0°C to +45 °C (32 to +113 °F)
Storage temperatures -20 °C to +60 °C (-4 to +140 °F)
Weight (approx.) 14.4 kg (31.7 lbs) without viewfinder support
Dimensions (L x W x H) 526 x 286 x 385 mm (20.7 x 11.3 x 15.2 in) without viewfinder and
lens
Power outputs
Utility power output 1 (fixed) 15 VDC; XLR-4 female connector, P
max
= 120 W *)
Utility power output 2 (variable)
(SuperXpander only) 0 to 12 VDC; XLR-4 female connector, Pmax = 50 W
*) The maximum power consumption of the two utility outputs combined is 120 W
Script light output 12 VDC; P
max
= 6 VA;
Fischer 3-pin female connector type DBP 103 A052-28
Connections
Lens interface 36-pin Centronics female connector
External CVBS output 1.0 Vpp ~ 75 Ohm; BNC socket
External Components outputs Y (1.0 Vpp with sync.), Pr (0.7 Vpp), Pb (0.7 Vpp); 3x BNC sockets
VF connector (camera) 20-pin female VF connector
VF connector (top) 15-pin Sub-D connector, female
