412 ICP programming
6.1
0
Cont
our elements on lat
e
ra
l surf
ace
In smart.Turn, ICP generates a G110.
HC Milling/drilling attribute:
 1: Contour milling
 2: Pocket milling
 3: Area milling
 4: Deburring
 5: Engraving
 6: Contour milling and deburring
 7: Pocket milling and deburring
 14: Do not machine
QF Milling location:
 0: On the contour
 1: Inside/left
 2: Outside/right
HF Direction:
 0: Up-cut milling
 1: Climb milling
DF Cutter diameter
WF Angle of the chamfer
BR Chamfer width
RB Return plane
