HEIDENHAIN CNC PILOT 620/640 587
1
0
.2 T
u
rn
ing cy
cles
10.2 Turning cycles
Turning cycles Page
Overview 142
Cut longitudinal
Roughing and finishing cycle for simple
contours 145
Cut transverse
Roughing and finishing cycle for simple
contours 147
Cut with longitudinal plunge
Roughing and finishing cycle for
simple contours 159
Plunge, transverse
Roughing and finishing cycle for simple
contours 161
ICP contour-parallel, longitudinal
Roughing and finishing cycle for any
type of contour 174
ICP contour-parallel, transverse
Roughing and finishing cycle for any
type of contour 176
ICP cut longitudinal
Roughing and finishing cycle for any
type of contour 182
ICP cut transverse
Roughing and finishing cycle for any
type of contour 184
