RISCO Group Orbit Pro RP-296 - Manual (Page 28)

user manual 20
Section 6: User Functions
Your ORBIT-PRO comes with a variety of selectable User Functions.
By entering the User Functions mode, a number of options become available,
To enter User Functions mode press [ ] followed by the Function index (see the
table below) and user code. To exit user function mode and return to normal
operation press [ ] [ ] quickly.
Example : To activate “Switch Auxiliary” press: [ ] [2] [2] [1-2-3-4] [ENTER]
To view trouble press [ ] [3] [1] [1-2-3-4] [ENTER]
Quick
Key
Item Explanation
1 Bypass
1
Bypass Zones
Provides the ability to bypass any of the system's intrusion
zones.
2 Bypass Reset Removes any bypass(es) previously placed on intrusion zone(s).
3 Bypass Recall Recalls the most recent zone bypass(es)
2 Activities
1
Utility Output
Allows user control of previously designated external devices
(e.g. an appliance, a motor-driven garage door, etc.)
[ ] [2] [1] [user code] [ENTER] [Output number] [ENTER]
in some cases only a code followed by ENTER required to
activate UO (i.e. to open a door).
2
Switch
Auxiliary
Interrupts the power supplied to the system's smoke detector(s)
for a predetermined interval, thus resetting and "readying" them
for subsequent alarms.
3
Terminate FM
If Follow Me Phone Number(s) were chosen, their operation can
be terminated. Use this function when an alarm has been tripped
and there is no need to utilize the Follow-Me phone call.
4
Initiate Call *
By initiating a call to your alarm company, allows them to
perform a remote programming operation on your system.
5
Hand Over *
Similar in intent to Initiate Call (above), Hand Over allows your
alarm company to call you and, during the call, "hand over" to
them, the control of your security system.
6
Void Rep Prg
For Installer Use Only
DO NOT USE
* Not for UL Installations
7
FM Phones
Allows the entry and/or editing of any phone numbers used with
the "Follow Me" feature. In case of alarm your system will
generate a phone call to a designated system phone or pager
user, and employ unique tones to express the active alarm
(either burglary or fire).
Up to 8 phone numbers can be used by the system.
To edit the phone number press:
[ ] [2] [7] [user code] [ENTER] [phone index 1-8] [phone
number] [ENTER]
