user manual
25
AC Loss in
Power
Supply
Module
relates to optional
Power Supply
Module(s)
NOTE: Here, the
system is reporting
that the first Power
Supply Module
(PS=1) has
experienced a loss of
AC Power.
ZONE 10 LED
WILL FLASH
(requires the
16-Zone LED
Keypad)
Make sure the
connection of
this module's
trafo to AC
power has not
been disturbed
Make sure that
the outlet into
which the
module's trafo
is plugged is
ON.
Bell
Trouble in
Power
Supply
Module
relates to optional
Power Supply
Module(s) NOTE: reporting that
the external
sounder(s) connected
to the first Power
Supply Module
(PS=1) is not
operating.
ZONE 11 LED
WILL FLASH
(requires the
16-Zone LED
Keypad)
contact your
dealer
Auxiliary
Power
Failure in
Power
Supply
Module
relates to optional
Power Supply
Module(s)
NOTE: reporting
that there is a failure
in the power to a
sensor connected to
the first Power
Supply Module
(PS=1).
ZONE 12 LED
WILL FLASH
(requires the
16-Zone LED
Keypad)
contact your
dealer
Day Zone
Trouble
a zone
designated as a
DAY ZONE has
been faulted
during the
disarmed period DESIGNATED
ZONE
WILL FLASH
(requires the
16-Zone LED
Keypad)
check the
integrity of the
indicated zone
Restoring
Troubles
to Normal
Depending on the nature of the trouble, you may be able to correct
it yourself--otherwise, your dealer (or other related services) may
have to get involved. Once all outstanding trouble(s) are
corrected, the rapidly flashing POWER LED on your keypad(s) will
light steadily and all evidence of the trouble(s) will automatically be
removed from your system.
TROUBLE:
PS=1 AC TRBL
TROUBLE:
PS=1 BELL TRBL
TROUBLE:
PS=1 AUX TRBL
TROUBLE:
FIRE DOOR : DAY
