Rosen Aviation 10.6” HD Widescreen Bulkhead Display
Document Number: 106282 Revision: D
Date: 03/20/14
Template: 4.4.1.6FM2; Revision A; 12/06/12 Page 13 of 30
5.3.3. Reset Scheme
Restores the values of the current scheme to their default settings, and it affects only the
current source. Use Reset Scheme to revert to the default screen colors if the other
Image Adjust options did not correct the screen quality.
Select Image AdjustReset Scheme and then press ENTER.
Press EXIT to close the OSD.
For information about the different Scheme modes, see Section 5.2.3 on page 11 .
5.3.4. Image Adjust Advanced (Submenu)
Use the Image Adjust Advanced submenu options, as shown below, to fine-tune the
primary screen colors and to restore
the monitor’s factory screen settings. Press the
MENU button and the ▼ button to select Image AdjustAdvanced, and then press
ENTER to open the menu.
To close the menu, select the Back option, or press EXIT to close the OSD.
Figure 10 Advanced submenu options
5.3.4.1. Color Temperature
Use the Color Temperature options to change the warmth of the picture in all sources.
When you select Color Temperature, the screen changes, and a toggle appears to
switch between User and 6500K, as shown below.
Figure 11 Color Temperature options
Select the User setting and then press ENTER.
Press
▼ to access the individual colors.
RGB
options
only
