Battery Protection Mechanisms
The battery LED indicators can display battery protection notifications triggered by abnormal charging
conditions.
If one of the battery protection mechanisms activate, unplug the charger, and then plug it in again to
resume charging. If the charging temperature is abnormal, wait for the charging temperature to return
to normal and the battery will automatically resume charging without the need to unplug and plug the
charger again.
Installing/Removing the Battery
Install the Intelligent Flight Battery in the aircraft before use. Insert the battery in the battery compartment
and secure the battery clamp. A clicking sound indicates the battery is fully engaged. Make sure that
the battery is fully inserted and the battery cover is secure in place.
LED1
LED2
LED3
LED4
Battery Level
0%
<
battery level ≤ 50%
50%
<
battery level ≤ 75%
75%
<
battery level
<
100%
Fully charged
The table below shows the battery level during charging.
The blinking frequency of the battery level LEDs will be different when using different USB chargers. If
the charging speed is fast, the battery level LEDs will blink quickly. If the charging speed is extremely
slow, the battery level LEDs will blink slowly (once every two seconds). It is recommended to change
the USB-C cable or USB charger.
If the battery is not correctly inserted into the aircraft, LED 3 and 4 blink simultaneously. Insert the
Intelligent Flight Battery again and make sure that it is securely mounted.
The four LEDs blink simultaneously to indicate the battery is damaged.
Battery Protection Mechanisms
LED1 LED2 LED3 LED4 Blinking Pattern
Battery Protection Item
LED2 blinks twice per second
Overcurrent detected
LED2 blinks three times per
second
Short circuit detected
LED3 blinks twice per second
Overcharge detected
LED3 blinks three times per
second
Over-voltage charger detected
LED4 blinks twice per second
Charging temperature is too low
LED4 blinks three times per
second
Charging temperature is too
high
