DJI MINI 2 SE
User Manual
Flight Limits
DJI Fly App
Aircraft Status
Indicator
Max
Altitude
Altitude of the aircraft cannot exceed
the specified value
Warning: height limit
reached
Blinks green and
red alternatively
Max
Radius
Flight distance must be within the
max radius
Warning: distance limit
reached
When GPS is weak
Flight Limits
DJI Fly App
Aircraft Status
Indicators
Max
Altitude
Height is restricted to 16 ft (5 m)
when the GPS signal is weak and
Infrared Sensing System is operating.
Height is restricted to 98 ft (30 m)
when the GPS signal is weak and
Infrared Sensing System is not
operating.
Warning: height limit
reached.
Blinks red and
green alternately
Max
Radius
The restrictions on the radius are disabled and warning prompts cannot be received in
the app.
There will be no altitude limit if the GPS signal becomes weak during flight as long as the GPS signal
was stronger than weak (white or yellow signal bars) when the aircraft was powered on.
If the aircraft is in a GEO zone and there is a weak or no GPS signal, the aircraft status indicator will
glow red for five seconds every twelve seconds.
If the aircraft reaches an altitude or radius limit, you can still control the aircraft, but you cannot fly it
any further. If the aircraft flies out of the max radius, it will automatically fly back within range when
the GPS signal is strong.
For safety reasons, do not fly close to airports, highways, railway stations, railway lines, city centers,
or other sensitive areas. Fly the aircraft only within your line of sight.
GEO Zones
All GEO zones are listed on the DJI official website at http://www.dji.com/flysafe. GEO zones are divided
into different categories and include locations such as airports, airfields where manned aircraft operate
at low altitudes, national borders, and sensitive locations such as power plants. By default, the GEO
system limits flights into or takeoffs within zones that may cause safety or security concerns.
You will receive a prompt in DJI Fly if your aircraft is approaching a GEO zone and the aircraft will be
restricted from flying in the area.
When GPS is available
