QUICK REFERENCE GUIDE
Rogue Outcast 2X Wash QRG Rev. 1
Color Chart
Zone Selection Chart
Value Percent/Setting Value Percent/Setting
000  004 No function 105  109 Color 21
005  009 Color 1 110  114 Color 22
010  014 Color 2 115  119 Color 23
015  019 Color 3 120  124 Color 24
020  024 Color 4 125  129 Color 25
025  029 Color 5 130  134 Color 26
030  034 Color 6 135  139 Color 27
035  039 Color 7 140  144 Color 28
040  044 Color 8 145  149 Color 29
045  049 Color 9 150  154 Color 30
050  054 Color 10 155  159 Color 31
055  059 Color 11 160  164 Color 32
060  064 Color 12 165  169 Color 33
065  069 Color 13 170  174 Color 34
070  074 Color 14 175  179 No function
075  079 Color 15 180  201 Color scroll, fast to slow
080  084 Color 16 202  207 Hold
085  089 Color 17 208  229 Reverse color scroll, fast to slow
090  094 Color 18 230  234 No function
095  099 Color 19 235  249 Color snap, fast to slow
100  104 Color 20 250  255 No function
Value Percent/Setting Value Percent/Setting
000  007 Zone 1, 2, 3, 4, 5 128  135 Zone 4, 5
008  015 Zone 1, 2, 3, 4 136  143 Zone 3, 4
016  023 Zone 1, 2, 3 144  151 Zone 2, 3
024  031 Zone 1, 2 152  159 Zone 1, 2
032  039 Zone 1 160  167 Zone 1, 5
040  047 No zones 168  175 Zone 3, 4, 5
048  055 Zone 5 176  183 Zone 2, 3, 4
056  063 Zone 4, 5 184  191 Zone 1, 2, 3
064  071 Zone 3, 4, 5 192  199 Zone 1, 2, 5
072  079 Zone 2, 3, 4, 5 200  207 Zone 1, 4, 5
080  087 Zone 1, 2, 3, 4, 5 208  215 Zone 2, 3, 4, 5
088  095 Zone 5 216  223 Zone 1, 2, 3, 4
096  103 Zone 4 224  231 Zone 1, 2, 3, 5
104  111 Zone 3 232  239 Zone 1, 2, 4, 5
112  119 Zone 2 240  247 Zone 1, 3, 4, 5
120  127 Zone 1 248  255 Zone 1, 2, 3, 4, 5
