3
EN
QUICK REFERENCE GUIDE
Rogue Outcast 2X Wash QRG Rev. 1
Control Panel Description
Menu Map
Refer to the Rogue Outcast 2X Wash product page on www.chauvetprofessional.com for the latest menu map.
Button Function
<MENU> Exits from the current menu or function
<ENTER> Enables the currently displayed menu or sets the currently selected value into the selected function
<UP> Navigates upwards through the menu list or increases the numeric value when in a function
<DOWN> Navigates downwards through the menu list or decreases the numeric value when in a function
Main Level Programming Levels Description
Address 001–512 Sets the starting address
Run Mode
DMX
56CH
( Advanced
Modes )
Selects the DMX personality
54CH
33CH
22CH
( Basic Modes ) 17CH
15CH
54MS
( MS Modes )
33MS
Auto Test Auto test all functions
Manual Test
Pan
0–255
Manually control and test all settings
through the control panel
Tilt
Dimmer
Shutter
Red1
Green1
Blue1
White1
Red2
Green2
Blue2
White2
Red3
Green3
Blue3
White3
Red4
Green4
Blue4
White4
Red5
Green5
Blue5
White5
Zoom
Setup
Pan Reverse
OFF Normal pan
ON Reversed pan
Tilt Reverse
OFF Normal tilt
ON Reversed tilt
