5
EN
QUICK REFERENCE GUIDE
Rogue Outcast 2X Wash QRG Rev. 1
DMX Values
Advanced Modes
Sys Info
Ver V_._ _ _ _ _ _ Shows firmware version
Running Mode _ _ _ Shows current running mode
DMX Address _ _ _ Shows current DMX address
Temperature _ _ _ Shows the product’s temperature in °C
Fixture Time _ _ _ _ Shows time product has been on
UID _ _ _ _ _ _ _ _ Shows product UID
Head Fan1–2 _ _ _ _ _
Shows speed of each fan
Base Fan1–2 _ _ _ _ _
33CH 54CH 56CH Function Value Percent/Setting
1 1 1 Pan 000  255 0–100%
2 2 2 Fine pan 000  255 Fine control (16-bit)
3 3 3 Tilt 000  255 0–100%
4 4 4 Fine tilt 000  255 Fine control (16-bit)
5 5 5 Pan/tilt speed 000  255 Fast to slow
6 6 6 Dimmer 000  255 0–100%
– 7 7 Fine dimmer 000  255 Fine control (16-bit)
7 8 8 Strobe 000  255 See Strobe Chart
8 9 9 Red 1 000  255 0–100%
– 10 10 Fine red 1 000  255 Fine control (16-bit)
9 11 11 Green 1 000  255 0–100%
– 12 12 Fine green 1 000  255 Fine control (16-bit)
10 13 13 Blue 1 000  255 0–100%
– 14 14 Fine blue 1 000  255 Fine control (16-bit)
11 15 15 White 1 000  255 0–100%
– 16 16 Fine white 1 000  255 Fine control (16-bit)
12 17 17 Red 2 000  255 0–100%
– 18 18 Fine red 2 000  255 Fine control (16-bit)
13 19 19 Green 2 000  255 0–100%
– 20 20 Fine green 2 000  255 Fine control (16-bit)
14 21 21 Blue 2 000  255 0–100%
– 22 22 Fine blue 2 000  255 Fine control (16-bit)
15 23 23 White 2 000  255 0–100%
– 24 24 Fine white 2 000  255 Fine control (16-bit)
16 25 25 Red 3 000  255 0–100%
– 26 26 Fine red 3 000  255 Fine control (16-bit)
17 27 27 Green 3 000  255 0–100%
– 28 28 Fine green 3 000  255 Fine control (16-bit)
18 29 29 Blue 3 000  255 0–100%
– 30 30 Fine blue 3 000  255 Fine control (16-bit)
19 31 31 White 3 000  255 0–100%
– 32 32 Fine white 3 000  255 Fine control (16-bit)
20 33 33 Red 4 000  255 0–100%
– 34 34 Fine red 4 000  255 Fine control (16-bit)
21 35 35 Green 4 000  255 0–100%
– 36 36 Fine green 4 000  255 Fine control (16-bit)
Main Level Programming Levels Description
