EN
10 Rogue Outcast 2X Wash QRG Rev. 1
QUICK REFERENCE GUIDE
Programs Chart
Control Chart
Value Percent/Setting Value Percent/Setting
000  015 No function
016  020 Zone program 1 136  140 Color program 1
021  025 Zone program 2 141  145 Color program 2
026  030 Zone program 3 146  150 Color program 3
031  035 Zone program 4 151  155 Color program 4
036  040 Zone program 5 156  160 Color program 5
041  045 Zone program 6 161  165 Color program 6
046  050 Zone program 7 166  170 Color program 7
051  055 Zone program 8 171  175 Color program 8
056  060 Zone program 9 176  180 Color program 9
061  065 Zone program 10 181  185 Color program 10
066  070 Zone program 11 186  190 Color program 11
071  075 Zone program 12 191  195 Color program 12
076  080 Zone program 13 196  200 Color program 13
081  085 Zone program 14 201  205 Color program 14
086  090 Zone program 15 206  210 Color program 15
091  095 Zone program 16 211  215 Color program 16
096  100 Zone program 17 216  220 Color program 17
101  105 Zone program 18 221  225 Color program 18
106  110 Zone program 19 226  230 Color program 19
111  115 Zone program 20 231  235 Color program 20
116  120 Zone program 21 236  240 Color program 21
121  125 Zone program 22 241  245 Color program 22
126  130 Zone program 23 246  250 Color program 23
131  135 Zone program 24 251  255 Color program 24
Value Percent/Setting Value Percent/Setting
000  009 No function
010  014 Blackout on pan/tilt 130  134 Fan mode Auto
015  049 Reserved for future use 135  139 Fast dimmer
050  054 Reset pan 140  144 Smooth dimmer
055  059 Reset tilt 145  149 Linear dimmer curve
060  064 Reset zoom 150  154 Square dimmer curve
065  069 Reserved for future use 155  159 Inverse square dimmer curve
070  074 Reset all 160  164 S-curve dimmer curve
075  099 Reserved for future use 165  169 White mode
100  104 Tilt range 260° 170  174 Full mode
105  109 Tilt range 180° 175  179 Color calibration off when single color
110  114 Tilt range 90° 180  184 Color calibration on when single color
115  119 Tilt range 230° 185  239 No function
120  124 Fan mode ECO 240  247 Color calibration on
125  129 Fan mode Full 248  255 Color calibration off
