QUICK REFERENCE GUIDE
Rogue Outcast 2X Wash QRG Rev. 1
MS Modes
10 9 11 Green 000  255 0–100%
– – 12 Fine green 000  255 Fine control (16-bit)
11 10 13 Blue 000  255 0–100%
– – 14 Fine blue 000  255 Fine control (16-bit)
12 11 15 White 000  255 0–100%
– – 16 Fine white 000  255 Fine control (16-bit)
13 12 17 Color 000  255 See Color Chart
– 13 18 Zone Selection 000  255 See Zone Selection Chart
– 14 19 Programs 000  255 See Programs Chart
– 15 20 Program Speed 000  255 0–100%
14 16 21 Zoom 000  255 0–100%
15 17 22 Control 000  255 See Control Chart
33MS 54MS Function Value Percent/Setting
1 1 Pan 000  255 0–100%
2 2 Fine pan 000  255 Fine control (16-bit)
3 3 Tilt 000  255 0–100%
4 4 Fine tilt 000  255 Fine control (16-bit)
5 5 Pan/tilt speed 000  255 Fast to slow
6 6 Dimmer 000  255 0–100%
– 7 Fine dimmer 000  255 Fine control (16-bit)
7 8 Strobe 000  255 See Strobe Chart
8 9 Color 000  255 See Color Chart
9 10 Zone Selection 000  255 See Zone Selection Chart
10 11 Programs 000  255 See Programs Chart
11 12 Program Speed 000  255 0–100%
12 13 Zoom 000  255 0–100%
13 14 Control 000  255 See Control Chart
14 15 Red 1 000  255 0–100%
– 16 Fine red 1 000  255 Fine control (16-bit)
15 17 Green 1 000  255 0–100%
– 18 Fine green 1 000  255 Fine control (16-bit)
16 19 Blue 1 000  255 0–100%
– 20 Fine blue 1 000  255 Fine control (16-bit)
17 21 White 1 000  255 0–100%
– 22 Fine white 1 000  255 Fine control (16-bit)
18 23 Red 2 000  255 0–100%
– 24 Fine red 2 000  255 Fine control (16-bit)
19 25 Green 2 000  255 0–100%
– 26 Fine green 2 000  255 Fine control (16-bit)
20 27 Blue 2 000  255 0–100%
– 28 Fine blue 2 000  255 Fine control (16-bit)
21 29 White 2 000  255 0–100%
– 30 Fine white 2 000  255 Fine control (16-bit)
22 31 Red 3 000  255 0–100%
– 32 Fine red 3 000  255 Fine control (16-bit)
23 33 Green 3 000  255 0–100%
– 34 Fine green 3 000  255 Fine control (16-bit)
15CH 17CH 22CH Function Value Percent/Setting
