CHAUVET PROFESSIONAL CHAUVET Rogue Outcast 2X Wash Outdoor-Ready IP65 Moving Head - Manual (Page 7)

EN
6 Rogue Outcast 2X Wash QRG Rev. 1
QUICK REFERENCE GUIDE
Basic Modes
22 37 37 Blue 4 000  255 0–100%
– 38 38 Fine blue 4 000  255 Fine control (16-bit)
23 39 39 White 4 000  255 0–100%
– 40 40 Fine white 4 000  255 Fine control (16-bit)
24 41 41 Red 5 000  255 0–100%
– 42 42 Fine red 5 000  255 Fine control (16-bit)
25 43 43 Green 5 000  255 0–100%
– 44 44 Fine green 5 000  255 Fine control (16-bit)
26 45 45 Blue 5 000  255 0–100%
– 46 46 Fine blue 5 000  255 Fine control (16-bit)
27 47 47 White 5 000  255 0–100%
– 48 48 Fine white 5 000  255 Fine control (16-bit)
28 49 49 Color 000  255 See Color Chart
29 50 50 Zone Selection 000  255 See Zone Selection Chart
30 51 51 Programs 000  255 See Programs Chart
31 52 52 Program Speed 000  255 0–100%
– – 53 Movement macros
000  007 No function
008  023 Movement macro 1
024  039 Movement macro 2
040  055 Movement macro 3
056  071 Movement macro 4
072  087 Movement macro 5
088  103 Movement macro 6
104  119 Movement macro 7
120  135 Movement macro 8
136  151 Movement macro 9
152  167 Movement macro 10
168  183 Movement macro 11
184  199 Movement macro 12
200  215 Movement macro 13
216  231 Movement macro 14
232  247 Movement macro 15
248  255 Movement macro 16
– – 54 Movement macro speed 000  255 Fast to slow
32 53 55 Zoom 000  255 0–100%
33 54 56 Control 000  255 See Control Chart
15CH 17CH 22CH Function Value Percent/Setting
1 1 1 Pan 000  255 0–100%
2 2 2 Fine pan 000  255 Fine control (16-bit)
3 3 3 Tilt 000  255 0–100%
4 4 4 Fine tilt 000  255 Fine control (16-bit)
5 5 5 Pan/tilt speed 000  255 Fast to slow
6 6 6 Dimmer 000  255 0–100%
7 – 7 Fine dimmer 000  255 Fine control (16-bit)
8 7 8 Strobe 000  255 See Strobe Chart
9 8 9 Red 000  255 0–100%
– – 10 Fine red 000  255 Fine control (16-bit)
33CH 54CH 56CH Function Value Percent/Setting
