EN
8 Rogue Outcast 2X Wash QRG Rev. 1
QUICK REFERENCE GUIDE
Zones for DMX Control
Strobe Chart
24 35 Blue 3 000  255 0–100%
– 36 Fine blue 3 000  255 Fine control (16-bit)
25 37 White 3 000  255 0–100%
– 38 Fine white 3 000  255 Fine control (16-bit)
26 39 Red 4 000  255 0–100%
– 40 Fine red 4 000  255 Fine control (16-bit)
27 41 Green 4 000  255 0–100%
– 42 Fine green 4 000  255 Fine control (16-bit)
28 43 Blue 4 000  255 0–100%
– 44 Fine blue 4 000  255 Fine control (16-bit)
29 45 White 4 000  255 0–100%
– 46 Fine white 4 000  255 Fine control (16-bit)
30 47 Red 5 000  255 0–100%
– 48 Fine red 5 000  255 Fine control (16-bit)
31 49 Green 5 000  255 0–100%
– 50 Fine green 5 000  255 Fine control (16-bit)
32 51 Blue 5 000  255 0–100%
– 52 Fine blue 5 000  255 Fine control (16-bit)
33 53 White 5 000  255 0–100%
– 54 Fine white 5 000  255 Fine control (16-bit)
Value Percent/Setting Value Percent/Setting
000  019 Off 145  149 On
020  024 On 150  164 Random strobe 0-100%, fast to slow
025  064 Strobe, fast to slow 165  169 On
065  069 On 170  184 Pulse strobe, fast to slow
070  084 Strobe 100-0%, fast to slow 185  189 On
085  089 On 190  204 Random pulse strobe, fast to slow
090  104 Strobe 0-100%, fast to slow 205  209 On
105  109 On 210  224 Strobe 100-0-100%, fast to slow
110  124 Random strobe, fast to slow 225  229 On
125  129 On 230  244 Random inverse pulse strobe, fast to slow
130  144 Random strobe 100-0%, fast to slow 245  255 On
33MS 54MS Function Value Percent/Setting
1 1
1
1 1
1
5
5
5
5 5
5
4
4 4
2
2 2
3
