QUICK REFERENCE GUIDE
Setup
(cont.)
Pan Angle
540 540° pan range
360 360° pan range
180 180° pan range
Tilt Angle
260 260° tilt range
180 180° tilt range
90 90° tilt range
230 230° tilt range
Fans
Auto
Fan speed according to product
temperature
ECO Quiet mode
Full Fan speed set on high
Display
OFF Display turns off
ON Display stays on
Screen Reverse
OFF Normal screen display
ON Inverted screen display
Dimmer Curver
Linear
Set the dimmer curve
Square
I Squa
SCurve
Dimmer Speed
Smooth Smooth dimmer speed
Fast Fast dimmer speed
PWM Option
600Hz
Sets the PWM frequency
1200Hz
2000Hz
4000Hz
6000Hz
15000Hz
LED R POWER 50–100 Sets red LED power
LED G POWER 50–100 Sets green LED power
LED B POWER 50–100 Sets blue LED power
LED W POWER 50–100 Sets white LED power
White Mode
On Calibrates white to 7500K
Off Uses maximum output values
Custom
RED 000–255 Sets red LED maximum value
GREEN 000–255 Sets green LED maximum value
BLUE 000–255 Sets blue LED maximum value
WHITE 000–255 Sets white LED maximum value
Color calibration
On Uses factory default white setting
Off Uses maximum output values
Custom
RED 100–255 Sets red LED maximum value
GREEN 100–255 Sets green LED maximum value
BLUE 100–255 Sets blue LED maximum value
USB Update
NO
Update firmware via USB C
YES
Reset Function
Pan/Tilt
NO
YES
Reset individual functions or all functions
from start-up
Zoom
All
Factory Settings
NO
Reset to factory default settings
YES
Main Level Programming Levels Description
