QuickSpecs
HP Z2 G9 Tower Workstation Desktop PC
System Technical Specifications
c08109687 — DA 17012 – Worldwide — Version 13 — November 1, 2022 Page 19
Support for Microsoft DirectX 12, OpenGL 4.6 and OpenCL 3.0
on Intel® UHD Graphics 730/770;
Based on Unified Memory Architecture (UMA) - a region of
system memory is reserved and dedicated to the graphics
display.
2 DP 1.4 graphics ports integrated in motherboard; Supports
up to three simultaneous displays across
DisplayPort*/HDMI*/DVI outputs.
Max. resolution supported on onboard DP 1.4/HBR2 ports:
4096x2304 @ 60Hz, 24bpp
Max. resolution supported on FlexIO DP 1.4/HBR3 port:
5120x3200 @60Hz, 24bpp
Network Controller Integrated Ethernet PHY Connection I219LM. Management
capabilities: WOL, PXE 2.1 and AMT 16
Serial 1 internal header (requires optional Serial Port and PS/2
Combo Kit with PCIe bracket)
2nd Serial 1 internal header(requires optional Serial Port Adapter Kit)
USB Connector(s) Front 2 Type-A SuperSpeed USB 10Gbps signaling rate port (charge
supports up to 5V/2.1A);
2 Type-A SuperSpeed USB 10Gbps signaling rate port; 1
Type-C® SuperSpeed USB 20Gbps signaling rate port
(optional, charge supports up to 5V/3A)
Rear 3 High-speed USB 480Mbps signaling rate port; 1 Type-A
SuperSpeed USB 5Gbps signaling rate port; 2 Type-A
SuperSpeed USB 10Gbps signaling rate port;
Flex I/O option:
1 SuperSpeed USB Type-C® 10Gbps signaling rate (Power
Delivery 15W, Alt Mode DisplayPort); 1 Dual SuperSpeed USB
Type-A 5Gbps signaling rate
Internal 1 High-speed USB 480Mbps signaling rate header for SD Card
Reader
HD Integrated Audio Realtek ALC3252
Flash ROM Yes
CPU Fan Header Yes
Memory Fan Header None
Chassis Fan Header 1 Rear System Chassis Fan Header, 1 Graphic chassis Fan Header.
Front PCI Fan Header None
Front Control
Panel/Speaker Header
Yes
CMOS Battery Holder -
Lithium
Yes
Integrated Trusted
Platform Module Integrated TPM 2.0 (Infineon SLB9672)
Convertible to FIPS 140-2 Certified mode through firmware v15.21
Power Supply Headers Yes
Power Switch, Power LED
& Hard Drive LED Header
Yes
Clear Password Jumper None
Keyboard/Mouse USB or PS/2 (option)
Power Supply 700W EPA92, 500W EPA90, 450W EPA90 and 350W EPA92
