HP Z2 G9 Tower Workstation - Manual (Page 46)

QuickSpecs
HP Z2 G9 Tower Workstation Desktop PC
Technical Specifications - Graphics
c08109687 — DA 17012 – Worldwide — Version 13 — November 1, 2022 Page 46
Linux® 64-bit (selected Enterprise distributions)
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html
NVIDIA® T600 4GB
Graphics* Form Factor Single Slot, Low Profile (2.7” H x 6.1” L)
Graphics Controller Turing architecture
Max Power: 40 Watts
Cooling Solution: Active fan heatsink
Bus Type PCI Express 3.0 x16
Memory 4GB GDDR6 Memory
Memory Bandwidth: 160 GB/s
Memory Interface: 128 bit
Connectors 4x mDP (Mini DisplayPort ™ ) 1.4 Connectors
Max simultaneous
displays - 4x 3840 x 2160 @ 120Hz
- 4x 5120 x 2880 @ 60Hz
- 2x 7680 x 4320 @ 60Hz
- supports Multi-Stream Transport (MST)
Shading Architecture DirectX 12 Shader Model 5.1
Supported Graphics APIs OpenGL 4.6
DirectX 12
Vulkan 1.2
API support includes:
CUDA, OpenCL 1.2
Available Graphics
Drivers Windows 10 64-bit
Windows 11 64-bit
Linux® 64-bit (selected Enterprise distributions)
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html
*May go End of Life in late 2022
AMD® Radeon ™ RX 6400
4GB Graphics
Form Factor Single slot, Low Profile (2.8” H x
6.3” L )
Weight: 155g
Graphics Controller Radeon ™ RX 6400
Max Power: 53W
Cooling Solution: Active axial fan
Architecture: RDNA
™ 2
Bus Type PCI Express x4 Gen4
Memory Size: 4GB GDDR6
Interface: 64-bit
Bandwidth: up to 128 GB/s
Connectors DP (DisplayPort ™ ) 1.4 + HDMI 2.1
Max simultaneous
displays - up to 4x 5120 x 2880 x 24 bpp @
60Hz
