HP Z2 G9 Tower Workstation - Manual (Page 7)

QuickSpecs
HP Z2 G9 Tower Workstation Desktop PC
Supported Components
c08109687 — DA 17012 – Worldwide — Version 13 — November 1, 2022 Page 7
Processors Factory
Configured Option Kit
Option Kit Part
Number
Support
Notes
12th Generation Intel® Core ™ Processors*
Intel® Core ™ i9-12900K Processor Y N
Intel® Core ™ i9-12900 Processor Y N
Intel® Core ™ i7-12700K Processor Y N
Intel® Core ™ i7-12700 Processor Y N
Intel® Core ™ i5-12600K Processor Y N
Intel® Core ™ i5-12600 processor Y N
Intel® Core ™ i5-12500 processor Y N
Intel® Core ™ i5-12400 processor Y N 1
Intel® Core ™ i3-12300 processor Y N 1
Intel® Core ™ i3-12100 processor Y N 1
NOTE:
ECC memory is supported on the following: Intel® Core ™ i9-12900K, Intel® Core ™ i9-12900, Intel®
Core ™ i7-12700K, Intel® Core ™ i7-12700, Intel® Core ™ i5-12600K, Intel® Core ™ i5-12600 and Intel® Core ™
i5-12500 processors
NOTE 1:
These processors support only non-ECC memory
NOTE 2: No iGfx. A discrete graphics card must be purchased at the same time.
SATA Hard Drives
Factory
Configured Option Kit
Option Kit Part
Number
500GB SATA 7200 rpm 6Gb/s 3.5" HDD Y Y LQ036AA
1TB SATA 7200 rpm 6Gb/s 3.5" HDD Y Y LQ037AA
2TB SATA 7200 rpm 6Gb/s 3.5" HDD Y Y QB576AA
1TB SATA 7200 rpm 6Gb/s 3.5" HDD (Enterprise Class) Y Y W0R10AA
2TB SATA 7200 rpm 6Gb/s 3.5" HDD (Enterprise Class) Y Y 2Z274AA
4TB SATA 7200 rpm 6Gb/s 3.5" HDD (Enterprise Class) Y Y K4T76AA
8TB SATA 7200 rpm 6Gb/s 3.5" HDD (Enterprise Class) Y Y 2Z273AA
12TB SATA 7200 rpm 6Gb/s 3.5" HDD (Enterprise Class) Y Y 5S461AA
500GB SATA 7.2K SED HDD Y Y D8N29AA
NOTE: For internal bay install, HDD option kits require separate purchase of 6Z9U6AA HP Z2 Tower
HDD Cable Kit. For external bay install, HDD options kits require separate purchase of 6Z9U6AA HP Z2
Tower HDD Cable Kit & NQ099AA HP Optical Bay HDD Mounting Bracket.
PCIe Solid State Drives
HP ZTurbo 512GB PCIe-Gen 4x4 TLC Z2 SSDKit Y Y 201G0AA/AT
HP ZTurbo 512GB PCIe-Gen 4x4 SED Z2 SSDKit Y Y 201F9AA
HP ZTurbo 1TB PCIe-Gen 4x4 TLC Z2 SSDKit Y Y 201F5AA/AT
HP ZTurbo 2TB PCIe-Gen 4x4 TLC Z2 SSDKit Y Y 201F8AA
Z Turbo 1TB 2280 PCIe-Gen4x4 Self Encrypted OPAL2 TLC
M.2 Z2 SSD Y Y 223A3AA/AT
Z Turbo 2TB 2280 PCIe-Gen4x4 Self Encrypted OPAL2 TLC
M.2 Z2 SSD Y Y 223A4AA/AT
256GB 2280 PCIe-4x4 NVMe Value M.2 Z2 Kit SSD Y Y 4M9Z1AA
